  • Ai tracking 4K single light gimbal camera
  • Colors:BLACK
  • Model No:SIP4KQ12
  • USD:1,350.00
Add to Basktet Inquiry Cart
Al photoelectric pod equipped with 4K,10x optical zoom movement,advanced AI recognition and multi-template filter tracking technology allow it adaptive to the movement of the target and effective zoom in the tracking process,showing more subtle target details
Detail

Introduction

SIP4KQ12 is an Al photoelectric pod equipped with 4K,10x optical zoom movement,advanced AI recogni- tion and multi-template filter tracking technology allow it adaptive to the movement of the target and effective zoom in the tracking process,showing more subtle target details

image.pngFeatures

 4K image quality,10x Optical zoom,40x effective hybrid zoom.

● Automatically detect and identify the target,detect the frame rate of 30FPS, with tracking and anti-occlusion 3-second target refind function.

 Support to calculate the center of the screen target longitude and latitude coordinates.

 J30J military connector,with good electromagnetic compatibility and environmental

adaptability.

image.png  image.png  image.png

Parameter



Name

Parameter

Name

Parameter

Material

Aircraft aluminum,Nylon

Control angle range

360°×N(Yaw)-120°~30°(Pitch)±40°(Roll)

Size

103(L)×88(W)×147(H)mm

Control mode

Speed control.Angle control

Weight

490±10g

Control signal

S.BUSTTL UARTTCPUDP

Zoom factor

10x Optical zoom/40x Max hybrid zoom

Video output

1920*1080@30fps

Visible light resolution

4K

Video storage

MP4

Target tracking mode

Recognition tracking,Feature tracking

Photo storage

JPG

          image.png   image.png  image.png


SIP4KQ12

The Ai target detection/recognition/tracking ultra light 4K image quality,10x Optical zoom, 12x12 x lossless Zoom,40x effective hybrid zoom 3-Axis IP output aviation material for Drone Gimbal Camera

SIP4KQ12 used sony 2.5k 2.5k movement Ai target detection/recognition/tracking drone gimbal integrated 10x optical zoom, 12xstable lossless zoom,40x effective max hybrid zoom high-precision professional 3-axis stabilized Pod Gimbal Camera. Multi-template filter tracking technology allow it adaptive to the movement of the target and effective zoom in the tracking process,showing more subtle target details. It is easy to perform the reconnaissance, surveillance and other tasks.  And the ground software supports PTZ control and zoom camera control. The PTZ adopts high-precision encoder FOC control scheme, which has the characteristics of high stability, small volume, ultra light weight and low power consumption. It committed to above 600mm wheelbase aircraft and more small operation platform to create high-end industry application scenarios.The camera adopts HD sensor with an 8 mega effective pixel. Support local TF card FAT 32 storage and wireless transmission. Supports1920*1080@30fps 2.5K@30FPS, 4K@25FPS, 1080P@60FPS, and 720P@120FPS slow motion video recording.

Feature

Ø With yaw follow and yaw lock mode

Ø One key to look down vertically,one key to center function.

Ø 10x optical zoom,12xstable lossless zoom with effective 40x hybrid zoom

Ø Support 4K resolution

Ø Double record TF card, support network reading and writing

Ø Light weight490±10g

Ø Ai target detection / ai recognition /ai tracking

Ø Size: 103(L)×88(W)×153(H)mm

Ø Support target positioning

Ø  Network and UART control modes

Ø Control signal: S.BUS, TTL UART, TCP, UDP

Ø AF time<1S

Ø Support to calculate the center of the screen target longitude and latitude coordinates

Ø Three-axis stabilization pod

Ø Quick release


SIP4KQ12  IP small 8MP network output ai tracking gimbal camera



                  image.png               image.png                image.png

Voltage

12v

Power Supply

6W

Gimbal Feature

Roll Angle

 ±6

Pitch Angle

 -120° ~ 30°

Yaw Angle

±36

Pitch and Roll Jitter Angle

±0.02°

Horizontal Jitter Angle

±0.03°

Protection rank

IP43

Installation method

Lower PTZ (factory default)/Upper PTZ (optional)

Quick-release

method

Trigger Quick-release locking structure

Working current

0.8A

Stable precision

0.52 mrad

Stable frequency

1250 Hz

Control accuracy

2.09 mrad

Attitude correction

Auto

Control signal

S.BUS. TTL UART(RS232 optional).  Network(TCP),UDP

Video interface

Network ×2

Working model

Follow yaw, lock yaw, 90° overlook,target tracking

Control mode

Speed control, angle control, point to move

Controllable rotation speed (default)

Min: 0.18 °/s, Max: 45 °/s

Visible light Camera Para

Sensor

1/2.8 inch SONY CMOS effective 8 mega pixels CMOS

Focal length

4.949.0mm(10x).

12x equivalent focal length: 58.8mm

40x Equivalent focal length:196mm

Zoom factor

10 x Optical Zoom / 12 x lossless Zoom

/ 40 x Max. Hybrid Zoom

Zoom control mode

Speed control. Factor control

AF time

1S Realtime focusing

Focus Mode

Auto/Manual

FOV

H: 66.1-7.65°. V: 35.2-4.12°

F-number

F=3.4 ~ 3.8

M.O.D.

1m(W)-20m(T)

Noise-signal ratio

38.3 dB

MEGA OIS

Auto

White balance

Auto

Color mode

Colourful/Standard (default)

/Brown/Black and white

Static pixel

Seven million

Image storage format

JPG3648*2052

Electronic stability

Support

Optical stabilization

Voluntarily

Video storage format

MP4

Video output format

 2560×1440@30fps

3840×2160@25fps

1920*1080@60fps

1280*720@120fps

Storage methods

Mirco SD: 32GB

AI Intelligent Tracking module

Automatically detect the target types

Typical targets, such as vehicles, ships, and personnel, etc

Number of multi-target assays

≥20

Minimum target size

At 3,636 pixels

Target detection rate

≥85%

Target recognition rate

≥80%

Target capture time

The 5 frames

false alarm rate

≤15%

tracing accuracy

1 Pixel

Anti-occlusion time

3 Seconds

Maximum target tracking field of view

Not more than 1 / 3 field of view

processing speed

≥30fps@1080P

Resistance to target deformation / occlusion

voluntarily

Target switching tracking

support

Target Localization

Location mode

Visual center point positioning

Positioning accuracy

20m(Under non complex terrain conditions)

Coordinate output type

Latitude and longitude(Gaussian coordinates)

Control Mode

SBUS, IP or serial port control

Ground Software Control

Windows and Android

Device Size

103mm×88mm×153.5mm

Work Condition

-20℃ ~ 70℃

Storage Condition

-30℃ ~ 80℃

Main application

Drone aerial photography

Weight (Not including dampers)

490±10g
