  • 4 axis 10L agricultural drone
  • Colors:red
  • Model No:TOPOAVIONICS-410L
  • USD:2,715.00
Add to Basktet Inquiry Cart
Detail

Factory wholesale fertilizer spraying seeding integrated drone
Plant protection drone pesticide spraying machine seeding fertilizer particles automatic return with agriculture special wireless remote control.


Product Parameter
Product name: Uav for agricultural plant protectionProduct model:TOPOAVIONICS-X410L
Product mix:Four axes and four OARSPesticide tank volume:10L
Product wheelbase:1300mmTake off weight:26.10kg
Product weight:11.27kgNo-load flight time:18-25min
Folded size:650*650*600mmSpray width:4-6m
Brushless motor:T8The spray amount on each time per sortie:8-12 m
Brushless ESC:FOC 12SSpeed per sortie:3-7m/s
Propeller Blade:3212Remote control:H12
Power Supply:12S  44.4VFlight control system: Jyi K++V2
Spraying method: pressure sprinklerLithium battery:12S  16000mAh
Function:
1. Equipped with high-definition camera, picture transmission system, data transmission system
2. AB 30 self-service flight,Break pesticide refill spray function, AB point can be extended or shortened arbitrarily.
3. Fully autonomous flight, map enclosure, flight enclosure function.
4. With searchlight, can work at night.
5. With screen remote control.
6. Practical supervision of background data.

1. Protect farmers away from pesticide poisoning, assure the best coverage and application of your pesticides or fertilizers.

2. 20 times spraying efficiency more than manual spraying, save pesticide and water.

3. Ready to flight, easy to use, take off and land vertically, suits to all terrains.

4. Autonomous intelligent flight with waypoints, fail-safe protection.

5. Carbon fiber folding frame and quick release propellers, save space and easy to transport.

Brand:  TOPOAVIONICS or customizing
Model Number:
Series TOPOAVIONICS-X410
10 liter drone


Function:Altitude Hold ModeHeadless , With Camera, With LED lights, with G-sensor, One Key Takeoff / Landing, APP Control, Voice control, With Remote Control, Foldable
Private Mold:NO
Operator Skill Level:Intermediate
Control Type:Remote Control
Usage:Agriculture Sprayer
Sprayer Type: Unmanned Aerial Vehicle(Uav)
Core Components:Engine, Pump.Motor
Motor:Brushless
Aircraft Weight:11.27kg
Demension: Folding size: 650*650*600mm
Propeller Diameter: 30 Inch
Supply Ability
Supply Ability 300 Set/Sets per Day
