Quantity(sets) | 1 - 1 | 2 - 10 | >10 |
Lead time (days) | 7 | 15 | To be negotiated |
Product Parameter | |
Product model:TOPOAVIONICS-F630L | Pesticide tank volume 30L |
Product mix: Six axes and six OARS | Take off weight: 62.2kg |
Product wheelbase: 2028mm | No-load flight time: 35min |
Empty weight:28kg | Spray width:5-7m |
Folded size: 1192*623*885mm | Spraying method: pressure sprinkler |
Product size: 2692*2619*885mm | Spray per sortie: 5.77-6.59 acre |
Blade specification: diameter x pitch: 36x7 inch | Spraying system parameters: height 4m, speed 5m/s, spraying amplitude 6m |
Maximum lifting speed: 5 m/s Maximum falling speed: 2 m/s Horizontal flight speed: 10 m/s Charging time: 20min | Maximum tilt angle: positioning mode: 30 degree GPS mode: 30 degree attitude mode: 30 degree Maximum rotation angular speed: 120 degree/s |
Maximum rotation angular speed: 120 degree/s | Maximum allowable wind speed ≤ 17.1 m/s (wind force level 7) |
Flight altitude: ≤ 4000m Flight humidity: < 90% Flight height: ≤ 30m | Satellite positioning module: GPS Hover accuracy: vertical: ± 0.5 m (when GPS positioning) |
works normally) horizontal: ± 2.5 m (when GPS positioning works normally) | Protection grade: IP67, dustproof and waterproof, can fly in moderate rain weather |
Brushless motor:X9 | Remote control:H12 |
Working temperature: - 20 degrees - 60 degrees | Flight control system: Jiyi K++V2 |
Power Supply:12-14S 44.4-51.8V | Lithium battery:14S 28000mAh |
Function: 1. Equipped with high-definition camera, picture transmission system, data transmission system 2. AB 30 self-service flight,Break pesticide refill spray function, AB point can be extended or shortened arbitrarily. 3. Fully autonomous flight, map enclosure, flight enclosure function. 4. With searchlight, can work at night. 5. With screen remote control. 6. Practical supervision of background data. |
1. Protect farmers away from pesticide poisoning, assure the best coverage and application of your pesticides or fertilizers.
2. 20 times spraying efficiency more than manual spraying, save pesticide and water.
3. Ready to flight, easy to use, take off and land vertically, suits to all terrains.
4. Autonomous intelligent flight with waypoints, fail-safe protection.
5. Carbon fiber folding frame and quick release propellers, save space and easy to transport.
Brand: TOPOAVIONICS or customizing
Model Number:Series TOPOAVIONICS-F630L 30 liter drone
